Model SA100 Switch Assembly

Brand: McCrometer, Inc
Does not ship to VA, United States
The SA100 switch assembly is a single assembly mounted on top of the flowmeter beneath the register assembly.

The switch assembly uses a fast acting direct drive system containing up to three geared wheels to provide a dry switch closure output at quantitative intervals determined by the meter multiplier.

The SA100 is contained in an aluminum housing, 4.25 inches in diameter and approximately 2 inches high.
The SA100 switch assembly is a single assembly mounted on top of the flowmeter beneath the register assembly.

The switch assembly uses a fast acting direct drive system containing up to three geared wheels to provide a dry switch closure output at quantitative intervals determined by the meter multiplier.

The SA100 is contained in an aluminum housing, 4.25 inches in diameter and approximately 2 inches high.

Specifications

Electrical Rating

  • 28 Vdc Max.
  • 5 A Resistive at 115 Vac 60 Hz

Enclosure, Body Material

  • Aluminum

Operating Temperature

  • -54° to 80° C (-65° to 180° F)
